HZ1000 Specifications and Features
The HZ1000 hydraulic breaker is a remarkable innovation in the field. With an operating weight of 761 kg and a length of 1994 mm, it offers a perfect balance of size and power. It has a working flow rate ranging from 80 – 110 L/min and an oil relief pressure of 190 kg/cm3. The working pressure of 150 – 170 kg/cm3 and an impact rate of 400 – 650 bpm ensure efficient operation. The 100 mm chisel diameter and 3/4 inch oil pipe nominal diameter are designed for optimal performance.
Power Source and Applicability
Powered by the pressure oil from the pump station of excavators or loaders, the HZ1000 is highly effective in tasks like digging building foundations and clearing floating stones and rock gaps in mud. It is specifically engineered to be suitable for excavators weighing 10 – 15 tons. The valve Assy position is internal, contributing to its compact and efficient design.
Material and Quality Assurance
Made with high-quality materials and processed using special precision technology, key parts such as the piston, main front, cylinder, and main rear are manufactured with the latest heat treatment equipment, guaranteeing excellent and stable quality.
Advantages over SB50
Compared to the well-known SB50, the HZ1000 stands out with its own set of advantages. It is highly efficient, allowing you to complete tasks in a fraction of the time it would take with manpower. It significantly reduces manpower costs as it requires less human effort compared to manual destruction. Despite its power, it has a low fuel consumption, saving your project budget. It also produces less noise pollution, creating a more comfortable working environment around construction or demolition sites. Moreover, when operated by an experienced operator, it reduces workplace risks, enhancing overall safety. Choose the HZ1000 hydraulic breaker for a reliable and high-performing solution in your excavation and demolition projects.
Specification
| Items | Unit | Specification |
|---|---|---|
| Model HZ | HZ1000 | |
| Model SB | SB50 | |
| Operating Weight (Side/Top/Box) | kg | 761/866/861 |
| Length (Side/Top/Box) | mm | 1994/2387/2354 |
| Working Flow Rate | L/min | 80-110 |
| Oil Relief Pressure | kg/cm3 | 190 |
| Working Pressure | kg/cm3 | 150-170 |
| Impact Rate | bpm | 400-650 |
| Chisel Diameter | mm | 100 |
| Oil Pipe Nominal Diameter | inch | 3/4 |
| Back Head Pressure | kg/cm3 | 16 |
| Accumulator Pressure | kg/cm3 | NA |
| Applicable Excavator Weight | ton | 10-15 |
| Valve Assy Position | Internal |
